Cleco 19RAA03AH3 Angle Nutrunner, 19 Series Clecomatic Clutch

Price: $2,166.30

Part Number: 19RAA03AH3

Cleco Pneumatic Clecomatic Clutch 19 Series Reversible Angle Nutrunner Square Drive: 3/8” Torque Range Tool Range: 6-30in-lbs. 0.7-3.4Nm Torque Range with Std. Spring: 6-24in-lbs. 0.7-2.7Nm Free Speed (rpm): 1,450 Overall Length: 12.7” / 321mm

To Purchase Parts for the Cleco 19 Series Clecomatic Clutch Angle Nutrunners Click Here

Cleco 19RAA03AH3 Angle Nutrunner, 19 Series Clecomatic Clutch Description

CLECO 19 Series CLECOmatic Clutch Angle Nutrunner. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners feature class-leading accuracy and repeatability, an external torque adjustment, sliding knob reverse, and are available with either a 1/4” or 3/8” square drive. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners feature a durable CLECOmatic Clutch that the best-in-class torque repeatability and long calibration cycle. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners feature a lightweight, ergonomic handle designed with the operator in mind. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners are engineered to suit a wide range of applications, from fast paced assembly to aerospace. The grip material on the CLECO 19 Series CLECOmatic Clutch Angle Nutrunners is tested to withstand a range of industrial chemicals. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners are tested and certified by a technician prior to shipment. CLECOmatic nutrunners shut off the instant the clutch reaches its adjustable preset torque. This action provides an accurate method of controlling torque without sacrificing tool speed. Square Drive: 3/8” Torque Range Tool Range: 6-30in-lbs. 0.7-3.4Nm Torque Range w/ Std. Spring: 6-24in-lbs. 0.7-2.7Nm Free Speed (rpm): 1,450 Overall Length: 12.7” / 321mm Weight: 1.8lbs / 0.8kg Head Height: 1.19” / 30mm Side to Center: 0.50” / 13mm Air Inlet NPT: 1/8” Min. Hose I.D: 3/16” SCFM: 11

To Purchase Parts for the Cleco 19 Series Clecomatic Clutch Angle Nutrunners Click Here

Technical Specifications

Additional information

Square Drive

3/8''

Torque Range

6-30in-lbs./0.7-3.4Nm

Torque Range w/ Std Spring

6-24in-lbs./0.7-2.7Nm

Free Speed (rpm)

1450

Overall Length

12.7''/321mm

Weight

1.8lbs/0.8kg

Head Height

1.19''/30mm

Side to Center

0.50''/13mm

Air Inlet NPT

1/8''

Min. Hose I.D

3/16''

SCFM

11

Cleco 19RAA03AH3 Angle Nutrunner, 19 Series Clecomatic Clutch Description

CLECO 19 Series CLECOmatic Clutch Angle Nutrunner. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners feature class-leading accuracy and repeatability, an external torque adjustment, sliding knob reverse, and are available with either a 1/4” or 3/8” square drive. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners feature a durable CLECOmatic Clutch that the best-in-class torque repeatability and long calibration cycle. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners feature a lightweight, ergonomic handle designed with the operator in mind. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners are engineered to suit a wide range of applications, from fast paced assembly to aerospace. The grip material on the CLECO 19 Series CLECOmatic Clutch Angle Nutrunners is tested to withstand a range of industrial chemicals. CLECO 19 Series CLECOmatic Clutch Angle Nutrunners are tested and certified by a technician prior to shipment. CLECOmatic nutrunners shut off the instant the clutch reaches its adjustable preset torque. This action provides an accurate method of controlling torque without sacrificing tool speed. Square Drive: 3/8” Torque Range Tool Range: 6-30in-lbs. 0.7-3.4Nm Torque Range w/ Std. Spring: 6-24in-lbs. 0.7-2.7Nm Free Speed (rpm): 1,450 Overall Length: 12.7” / 321mm Weight: 1.8lbs / 0.8kg Head Height: 1.19” / 30mm Side to Center: 0.50” / 13mm Air Inlet NPT: 1/8” Min. Hose I.D: 3/16” SCFM: 11

To Purchase Parts for the Cleco 19 Series Clecomatic Clutch Angle Nutrunners Click Here

Additional information

Square Drive

3/8''

Torque Range

6-30in-lbs./0.7-3.4Nm

Torque Range w/ Std Spring

6-24in-lbs./0.7-2.7Nm

Free Speed (rpm)

1450

Overall Length

12.7''/321mm

Weight

1.8lbs/0.8kg

Head Height

1.19''/30mm

Side to Center

0.50''/13mm

Air Inlet NPT

1/8''

Min. Hose I.D

3/16''

SCFM

11
